Ronan X96S MASS FLOW GAUGE - Manual (Page 13)

9
Continued from
Previous Page
Hardware Cont’d.
Configuration Source Type
System Hardware
Operation Source Type Source Type [type]
Mass Flow Flow Rate Hardware Usr Def Source [S.O.#]
Density Proc Temp Next Reference [date]
Flow Rate Solids Adj. Hardware Next Wipe Test [date]
Head Temp Analog Out Config Next Shutter Test [date]
Display Totalizer HART Output
Remote Totalizer Com1 Protocol [type] Flow Rate Hardware
PD Counter [Select]
Alarms Hart Flow Pulse
Auto Reference Line Down
Hardware Tag Name [name] Tachometer
Hart MultiDrop [number] Ion/Scnt Ch#2
System Univ Rev [number] None
Spec Rev [number]
Proc Temp
System [Select]
None
Serial # [number] PT100, a=385
Hardware Rev [rev] PT100, a=392
Software Rev [rev] Ni120
Date [date] 0-10 volts
Hour (0-23) [hour] 4-20 ma
Minute [min]
Password
Solids Adj. Hardware
Date/Time Format [sel] [Select]
Analog Input #1
Analog Input #2
Pulse Counter #1
Pulse Counter #2
None
Analog Out Config
Loop 1 (PV) [details]
Loop 2 (SV) [details]
Loop 3 (TV) [details]
Pwr Src [int/ext]
[Select]
X96S-2005
X96S-2004 ch. 1
X96S-2004 ch. 2
None
HART Output
[Select]
None
X96S-2005
Ser. Port 1
Com1 Protocol
[Select]
None
HART
Modbus
Figure 3-2 – Configuration Menus Continued
