Aux Loop Cfg Menu
This menu is used to access the secondary 4-20ma loop calibration procedures. It contains the following items:
ITEM FUNCTION
SV is Shows and allows the user to set the variable assigned to the secondary 4-20ma current
loop
Aux 1 Test This item invokes a method that performs a test on the secondary 4-20ma current loop
Aux 1 trim This item invokes a method that performs the D/A trimming of the secondary 4-20ma
current loop
TV is Shows and allows the user to set the variable assigned to the tertiary 4-20ma current
loop
Aux 2 Test This item invokes a method that performs a test on the tertiary 4-20ma current loop
Aux 2 Trim This item invokes a method that performs the D/A trimming of the tertiary 4-20ma
current loop
SV is one of the following:
ITEM MEANING
Mass Flow Mass Flow (example: pounds per hour)
Density Density (example: pounds per linear foot)
Flow Rate Flow Rate (example: feet per second)
Head Temp Head Temperature (if Available)
Not Assigned Blank line
TV is one of the following:
ITEM MEANING
Mass Flow Mass Flow (example: pounds per hour)
Density Density (example: pounds per linear foot)
Flow Rate Flow Rate (example: feet per second)
Head Temp Head Temperature (if Available)
Not Assigned Blank line
Diagnostic
This menu is used to provide the available variables needed to troubleshoot on one simple screen. It contains the following:
ITEM FUNCTION
Density Selecting this item takes the user to the Density menu
Flow Rate Selecting this item takes the user to the Flow Rate Menu
Alarms Selecting this item takes the user to the Alarms menu
