25
Hardware
The Hardware menu is used to define the type of hardware used to provide measurements and radiation. It contains the following
items:
ITEM FUNCTION
System Hardware Shows the user to a list of the hardware modules in the system and the status of
these modules
Source Type Selecting this item takes the user to the Source Type menu
Flow Rate Hardware Selecting this item takes the user to the Speed Hardware menu
Proc Temp Shows and allows the user to set the type of probe used to read process temperature
Solids Adj.Hardware Shows and allows the user to set the density of the solids via an input.
Analog Out Cnfg Shows and allows the user to set the where the source of power is internal or
external
HART Output Shows and allows the user to adjust the HART output functions
Com1 Protocol Shows and allows the user to adjust the Com1 Protocols
(None/Hart/ModBus/RonanSetup)
System Hardware
The System Hardware menu takes the user to a list of the hardware modules in the system and shows the status of these modules.
It contains the following items:
ITEM FUNCTION
CPU Shows the type of CPU card installed (in slot 1)
Slot 1 Details Shows the status of the card and details of the hardware and software
Slot 2 Card Shows the type of card (if any) installed in slot 2
Slot 2 Details Shows the status of the card and details of the hardware and software
Slot 3 Card Shows the type of card (if any) installed in slot 3
Slot 3 Details Shows the status of the card and details of the hardware and software
Slot 4 Card Shows the type of card (if any) installed in slot 4
Slot 4 Details Shows the status of the card and details of the hardware and software
Slot 5 Card Shows the type of card (if any) installed in slot 5
Slot 5 Details Shows the status of the card and details of the hardware and software
Slot 6 Card Shows the type of card (if any) installed in slot 6
Slot 6 Details Shows the status of the card and details of the hardware and software
Slot 7 Card Shows the type of card (if any) installed in slot 7
Slot 7 Details Shows the status of the card and details of the hardware and software
Slot 8 Card Shows the type of card (if any) installed in slot 8
Slot 8 Details Shows the status of the card and details of the hardware and software
Display Type Shows the type of display module (if any) attached
Display Details Shows the status of the display module, if the module is attached, else shows None
Field Interface Shows the status of the card and details of the hardware and software
HART DB Details Shows the status of the card and details of the hardware and software
