Ronan X96S MASS FLOW GAUGE User Manual

Page 61

Quick Start Reference – Calibrating Flow Rate
(For Completion of a Single Point Reference)

Ronan Engineering
X96S Mass Flow Gauge
Main Menu
Variables
Status Display
Configuration

Digital Outputs
Digital Inputs

→

Calibration

Diagnostics

Step 1 Low Reference Flow Calibration

(Have a “0” flow input ready)

Scroll down

↓ to “Calibration” Press → to enter menu

Scroll down

↓ to “Cal Flow Rate” Press the → to enter menu

Scroll down

↓ to “Low Reference” Press the → to enter menu

Select “Low Flow Rate Cal” press

→ to enter menu

Read the next screen carefully and acknowledge by pressing the F4
(OK) Key. Referencing will begin. (This may take several minutes.)

Scroll down

↓ to “Low Flow Rate” Press → to enter menu

Notice the value that is displayed.
Use

← Key and → Key to toggle back and forth between digits.

Change the value using

↑ or ↓

Enter the value of the process (Example 0.0000 Gal per minute).
Press The F4 Key to enter and store the value.
Press the F3 Key (Home) to return to the Main Menu.

Ronan Engineering
X96S Mass Flow

Gauge

Low Reference

→Low Flow Rate Cal

Low Flow Rate 0.000
Ref Cap Value 20000

HOME
