14
Status Display Menu
The Status Display menu is used to configure the device status display. It contains the following items
ITEM FUNCTION
Analog Bar Shows the current state of the analog bar display (enabled or disabled) and allows the
user change the state.
Line 1: Shows the data to be displayed on line 1 of the status display and allows the user to
change the selection.
Line 2: Shows the data to be displayed on line 2 of the status display and allows the user to
change the selection.
Line 3: Shows the data to be displayed on line 3 of the status display and allows the user to
change the selection.
Line 4: Shows the data to be displayed on line 4 of the status display and allows the user to
change the selection.
Line 5: Shows the data to be displayed on line 5 of the status display and allows the user to
change the selection.
Line 6: Shows the data to be displayed on line 6 of the status display and allows the user to
change the selection.
Line 7: Shows the data to be displayed on line 7 of the status display and allows the user to
change the selection.
Line 8: Shows the data to be displayed on line 8 of the status display and allows the user to
change the selection.
Lines 1 through 8 can select one of the following:
ITEM MEANING
Mass Flow Mass Flow (example: pounds per hour)
Density Density (example: pounds per gallons)
Flow Rate Flow Rate (example: feet per second)
Totalizer Totalizer (shows the accumulated flow)
PD Counter PD Counter (shows the current value in the predetermined counter)
% of Density Shows the percent of Density based upon the min and max Density range
% of Mass Flow Shows the percent of Mass Flow based upon the min and max Mass Flow range
% of Flow Rate Shows the percent of Flow Rate based upon the min and max Flow Rate range
Head Temp Head Temperature (if Available)
Proc Temp Shows the temperature of the process in Deg F, Deg C, Deg R, Kelvin
4-20 mA Shows the 4-20 mA output level
Raw Cnts Unfiltered counts (from scintillation detector) or raw analog measurement (from
ionization detector)
Filt Cnts Filtered counts (from scintillation detector) or filtered analog measurement (from
ionization detector)
Date & Time Current date and time
Tot Elapsed Time Shows the Total Elapsed Time since the last time Totalizer was reset
Diagnostic Selecting this option takes the user to the Diagnostic Menu
Not Assigned Blank line
