6-20 Communications
Registers (Cont'd)
Motion Detection (Cont.)
40284 Low Motion Detection RPM
Read/write
Values: 0 - n
Motion detection low limit for the level specified by the index register.
40285 High Motion Detection RPM
Read/write
Values: 0 - n
Motion detection high limit for the level specified by the index register.
Analog Output
40286 Analog Output Mapping
Read/write
Values: 17 - 255
General purpose register used for mapping analog offset and high RPM values. Two regis-
ters will be used; the first will contain the analog offset value, the second will contain the high
RPM value.
40287 Channel Index
Read/write
Values: 1, 2
Analog channel index for analog offset and high RPM values.
40288 Analog Offset
Read/write
Values: 0 - 4095
Analog output at 0 RPM.
40289 Analog High RPM
Read/write
Values: 0 - 3000
RPM at which analog output is 4095.
Gray Code Speed Compensation
40290 Gray Code Speed Comp
Read/write
Values: 0 - n (.1mS)
In controllers equipped with the "-G" option, the Gray code bit pattern is speed compensated
by this amount.
Mapping Registers
40296 Map Limit
Read/write
Values: 0 - 256
Sets the maximum number of data mappings.
40297 Map Quantity
Read/write
Values: 0 - 256
Returns the number of data mappings active in the controller.
NOTE: Writing a '0' to this register will delete all data mappings!
40298 Map Store
This register is only for use by utility programs.
40299 Map Recall
This register is only for use by utility programs.
