Page 77
6-5 Communications
CMD
(hex)
Name
Function
56
Kbd Qty
Number of keypads connected.
Put:
! ADR 56 P XX CSM
Reply:
A
Get:
! ADR 56 G CSM
Reply:
A XX CSM
where “XX” = number of keypads connected.
0D
Setup ID
Setup ID code.
Put:
! ADR 0D P XXXX CSM
Reply:
A
Get:
! ADR 0D G CSM
Reply:
A XXXX CSM
where “XXXX” = Setup Enable Code in hex.
0E
Operator ID
Operator ID code.
Put:
! ADR 0E P XXXX CSM
Reply:
A
Get:
! ADR 0E G CSM
Reply:
A XXXX CSM
where “XXXX” = Operator Enable Code in hex.
58
Master ID
Master ID code.
Put:
! ADR 58 P XXXX CSM
Reply:
A
Get:
! ADR 58 G CSM
Reply:
A XXXX CSM
where “XXXX” = Master Enable Code in hex.
0F
User Pgm
User programming enable/disable.
Put:
! ADR 0F P XX <00 or 01> CSM
Reply:
A
Get:
! ADR 0F G XX CSM
Reply:
A <00 or 01> CSM
where “XX” is the channel number minus 1, in hex. “00” =
disable, and “01” = enable.
10
Motion Enab
Motion detection on/off for a specified output channel.
Put:
! ADR 10 P XX <00, 01, or 02> CSM
Reply:
A
Get:
! ADR 10 G XX CSM
Reply:
A <00, 01, or 02> CSM
where “XX” is the channel number minus 1, in hex. “00” = L1 &
L2 off; “01” = L1 on; “02” = L2 on.
Configuration
Commands
Serial Commands (cont’d)
