6-6 Communications
CMD
(hex)
Name
Function
12
Inc Direction
Direction of increasing rotation.
Put:
! ADR 12 P <00 or 01> CSM
Reply:
A
Get:
! ADR 12 G CSM
Reply:
A <00 or 01> CSM
where “00” = CCW, and “01” = CW
13
Scale Factor
Scale factor.
Put:
! ADR 13 P XXXX CSM
Reply:
A
Get:
! ADR 13 G CSM
Reply:
A XXXX CSM
where “XXXX” = scale factor in hex.
48
Lo Limit
Motion detection low limit.
Put:
! ADR 48 P <00 or 01> YYYY CSM
Reply:
A
Get:
! ADR 48 G <00 or 01> CSM
Reply:
A YYYY CSM
where “YYYY” = low limit RPM in hex. “00” = Level 1, “01” =
Level 2.
49
Hi Limit
Motion detection high limit.
Put:
! ADR 49 P <00 or 01> YYYY CSM
Reply:
A
Get:
! ADR 49 G <00 or 01> CSM
Reply:
A YYYY CSM
where “YYYY” = high limit RPM in hex. “00” = Level 1, “01” =
Level 2.
17
Time Delay
Delay value for Timed Output channels.
Put:
! ADR 17 P XX YYYY CSM
Reply:
A
Get:
! ADR 17 G XX CSM
Reply:
A YYYY CSM
where “XX” is the channel minus 1, in hex, and “YYYY” is the
delay in msec, in hex.
18
Default Pgm
Default program.
Put:
! ADR 18 P XXXX CSM
Reply:
A
Get:
! ADR 18 G CSM
Reply:
A XXXX CSM
where “XXXX” is the Default Program minus 1, in hex.
Configuration
Commands
(cont’d)
Serial Commands (cont’d)
