A-3 Appendix
Transistor Output Specifications
Sinking Transistor Output
Part # PS-9011-2803
Output Type:
Current Sinking (NPN)
Output Voltage:
5 to 30 VDC
Output Current:
50 milliamp cont. max (each output)
Sourcing Transistor Output
Part # PS-9011-2580
Output Type:
Current Sourcing (PNP)
Output Voltage:
5 to 30 VDC
Output Current:
50 milliamp cont. max (each output)
Resolver Specifications
Operating Temp:
-40
°
to 125
°
C (-40
°
to 257
°
F)
Storage Temp:
-40
°
to 125
°
C (-40
°
to 257
°
F)
Operating Humidity:
95% Relative non-condensing
NEMA Rating:
NEMA 4
NEMA 4X
Maximum RPM:
3000 RPM
Max Cable Length:
1000 Ft.
Type:
Single Turn - Brushless
Resolution (all):
12 Bits (4096 increments)
Linearity (standard):
+/-20 arc minutes (resolver only)
(+/-30 arc minutes combined with R/D converter in controller)
Linearity (specials):
+/-3 to +/-10 arc minutes (resolver only)
(+/-7 to +/-14 arc minutes combined with R/D converter in controller)
Note: A resolver’s linearity errors are repeatable at all positions of its 360 degree rotation.
Therefore, once appropriate setpoints are established, machine performance is consistent every cycle.
Factory Defaults
Analog Outputs
Quantity:
0
Offset:
0
High RPM:
2000
Communications
Type:
RS-485
Baud Rate:
9600
Default Program:
1
Enable Codes
Operator:
1
Setup:
2
Master:
3
Enable Options:
ON for all functions
Increasing Direction:
CCW
Input ANDing:
OFF
Keyboard Quantity:
1
Motion ANDing:
OFF
Motion Detection:
Lo 10 RPM, Hi 3000 RPM both levels
Offset:
0
Per Channel Enable:
All channels ON
Program Select Mode:
BIN (Binary)
Rate:
1X, RPM
RPM Update:
1/S
Output Enable ANDing:
OFF
Speed Comp:
All channels 0
Toggle RPM:
20 RPM
