6-15 Communications
Mapping Registers
40296 Map Limit
40297 Map Quantity
40298 Map Store
40299 Map Recall
Model Information
40300 Model
40301 Revision
40302 Output Quantity
40303 Option Index
40304 Option
Hardware Configuration
40305 Keyboard Quantity
40306 Increasing Direction
40307 Scale Factor
40308 Shaft Position
40309 Shaft Offset
40310 Analog Quantity
40311 Resolver Type
40312 Program Select Mode
40313 Gray Level
40314 Time Base
40315 Termination Resistor One
40316 Termination Resistor Two
Display Configuration
40317 Default Display
40318 Rate Multiplier
40319 Rate Divisor
40320 Rate Decimal Point Position
40321 Rate Units
40322 Toggle RPM
40323 RPM Update Rate
40324 Speed Comp Display Mode
40325 Group Position Display Mode
Password ID Numbers
40326 Operator ID
40327 Setup ID
40328 Master ID
Per Channel Enable
40329 Per Channel Enable
Index
40330 Per Channel Enable
Operator Function Enable
40331 Operator Function
Enable Bitmask
Motion ANDing
40332 Channel Index
40333 Motion Enable Level
Output Enable ANDing
40334 Output Enable Index
40335 Output Enable
Group Programming
40336 Group Quantity
40337 Group Index
40338 Channel Quantity
40339 Group Mode
Run Time Control
40340 Stop Control
40341 EEPROM Checksum
40342 EEPROM Changed
The following registers are not supported by early versions
of Modbus Controllers.
Active Program
40343 Active Program
I/O Control
40350 - 40359 Input Status
40360 - 40369 Output Status
40370 - 40379 ORing Bits
40380 - 40389 ANDing Bits
Communications
40390 Type (RS485/RS232)
40391 Baud Rate
40392 Address
Quick Reference
