2-7 Installation & Wiring
Controller Input Wiring (cont’d)
Figure 8—Program Select Terminals for Various Formats
BCD Format
Binary Format Gray Code Format
Input Terminal: 6 5 4 3 2 1
Value: 32 16 8 4 2 1
Program: Default 0 0 0 0 0 0
1 0 0 0 0 0 1
2 0 0 0 0 1 0
3 0 0 0 0 1 1
4 0 0 0 1 0 0
5 0 0 0 1 0 1
6 0 0 0 1 1 0
7 0 0 0 1 1 1
8 0 0 1 0 0 0
9 0 0 1 0 0 1
10 0 0 1 0 1 0
11 0 0 1 0 1 1
12 0 0 1 1 0 0
13 0 0 1 1 0 1
14 0 0 1 1 1 0
15 0 0 1 1 1 1
16 0 1 0 0 0 0
17 0 1 0 0 0 1
18 0 1 0 0 1 0
19 0 1 0 0 1 1
20 0 1 0 1 0 0
21 0 1 0 1 0 1
22 0 1 0 1 1 0
23 0 1 0 1 1 1
24 0 1 1 0 0 0
25 0 1 1 0 0 1
26 0 1 1 0 1 0
27 0 1 1 0 1 1
28 0 1 1 1 0 0
29 0 1 1 1 0 1
30 0 1 1 1 1 0
31 0 1 1 1 1 1
32 1 0 0 0 0 0
33 1 0 0 0 0 1
34 1 0 0 0 1 0
35 1 0 0 0 1 1
36 1 0 0 1 0 0
37 1 0 0 1 0 1
38 1 0 0 1 1 0
39 1 0 0 1 1 1
40 1 0 1 0 0 0
41 1 0 1 0 0 1
42 1 0 1 0 1 0
43 1 0 1 0 1 1
44 1 0 1 1 0 0
45 1 0 1 1 0 1
46 1 0 1 1 1 0
47 1 0 1 1 1 1
48 1 1 0 0 0 0
Input Terminal: 6 5 4 3 2 1
Value: MSB LSB
Program: Default 0 0 0 0 0 0
1 0 0 0 0 0 1
2 0 0 0 0 1 1
3 0 0 0 0 1 0
4 0 0 0 1 1 0
5 0 0 0 1 1 1
6 0 0 0 1 0 1
7 0 0 0 1 0 0
8 0 0 1 1 0 0
9 0 0 1 1 0 1
10 0 0 1 1 1 1
11 0 0 1 1 1 0
12 0 0 1 0 1 0
13 0 0 1 0 1 1
14 0 0 1 0 0 1
15 0 0 1 0 0 0
16 0 1 1 0 0 0
17 0 1 1 0 0 1
18 0 1 1 0 1 1
19 0 1 1 0 1 0
20 0 1 1 1 1 0
21 0 1 1 1 1 1
22 0 1 1 1 0 1
23 0 1 1 1 0 0
24 0 1 0 1 0 0
25 0 1 0 1 0 1
26 0 1 0 1 1 1
27 0 1 0 1 1 0
28 0 1 0 0 1 0
29 0 1 0 0 1 1
30 0 1 0 0 0 1
31 0 1 0 0 0 0
32 1 1 0 0 0 0
33 1 1 0 0 0 1
34 1 1 0 0 1 1
35 1 1 0 0 1 0
36 1 1 0 1 1 0
37 1 1 0 1 1 1
38 1 1 0 1 0 1
39 1 1 0 1 0 0
40 1 1 1 1 0 0
41 1 1 1 1 0 1
42 1 1 1 1 1 1
43 1 1 1 1 1 0
44 1 1 1 0 1 0
45 1 1 1 0 1 1
46 1 1 1 0 0 1
47 1 1 1 0 0 0
48 1 0 1 0 0 0
Units 10's
Input Terminal: 7 6 5 4 3 2 1
Value: 40 20 10 8 4 2 1
Program: Default 0 0 0 0 0 0 0
1 0 0 0 0 0 0 1
2 0 0 0 0 0 1 0
3 0 0 0 0 0 1 1
4 0 0 0 0 1 0 0
5 0 0 0 0 1 0 1
6 0 0 0 0 1 1 0
7 0 0 0 0 1 1 1
8 0 0 0 1 0 0 0
9 0 0 0 1 0 0 1
10 0 0 1 0 0 0 0
11 0 0 1 0 0 0 1
12 0 0 1 0 0 1 0
13 0 0 1 0 0 1 1
14 0 0 1 0 1 0 0
15 0 0 1 0 1 0 1
16 0 0 1 0 1 1 0
17 0 0 1 0 1 1 1
18 0 0 1 1 0 0 0
19 0 0 1 1 0 0 1
20 0 1 0 0 0 0 0
21 0 1 0 0 0 0 1
22 0 1 0 0 0 1 0
23 0 1 0 0 0 1 1
24 0 1 0 0 1 0 0
25 0 1 0 0 1 0 1
26 0 1 0 0 1 1 0
27 0 1 0 0 1 1 1
28 0 1 0 1 0 0 0
29 0 1 0 1 0 0 1
30 0 1 1 0 0 0 0
31 0 1 1 0 0 0 1
32 0 1 1 0 0 1 0
33 0 1 1 0 0 1 1
34 0 1 1 0 1 0 0
35 0 1 1 0 1 0 1
36 0 1 1 0 1 1 0
37 0 1 1 0 1 1 1
38 0 1 1 1 0 0 0
39 0 1 1 1 0 0 1
40 1 0 0 0 0 0 0
41 1 0 0 0 0 0 1
42 1 0 0 0 0 1 0
43 1 0 0 0 0 1 1
44 1 0 0 0 1 0 0
45 1 0 0 0 1 0 1
46 1 0 0 0 1 1 0
47 1 0 0 0 1 1 1
48 1 0 0 1 0 0 0
For BCD, calculate the program selected by
adding up the values for each of the inputs that
are on. For example, if Inputs 5, 3, and 1 are on,
Program #15 is active (10 + 4 + 1).
• Only three of the normal four BCD digits for
10’s are used.
• 9 is the largest valid value for the units
digit. A units digit combination larger than 9
will set the units digit to 9.
Electro Cam 8-position Gray Code selector
switches are available as accessories for PS-
6144 and other PLuS controls. For Binary, calculate the program selected by
adding up the values for each of the inputs that
are on. For example, if Inputs 5, 3 and 1 are on,
Program #21 is active (16 + 4 + 1).
Notes Common to All Three Formats
• Because the standard PS-6144 has 48 programs available, any program select value larger than 48 selects program number 48.
• The Default Program is determined by programming the DEFAULT PROGRAM function, Section 3.
