3-12 Programming
Keyboard Quantity
Menu Path MAIN SCREEN to CONFIG MENU HARDWARE MENU KEYBOARD
QTY
Purpose The Keyboard Quantity screen shows the number of keypads the controller will com-
municate with.
Screen
The controller will attempt to establish communication with as many keypads as are
programmed through this screen. Keypads are assumed to be addressed sequentially,
starting at address “0” as shown in Fig. 14.
Keypad “0” You can change the number of keypads shown in KEYBOARD QTY only from the
keypad whose address is “0.”
If KEYBOARD QTY is set to “2,” but only one keypad is physically connected,
Menu Tree operation will be very slow. Change KEYBOARD QTY to “1” to restore
normal Menu Tree speed.
KEYBOARD
QTY: 1<
Number of keyboard/display units
attached to controller
Input Status
Menu Path MAIN SCREEN to SETUP MENU to I/O STATUS
to INPUT STATUS
The input status screen displays the On/Off status of the DC inputs on Terminal Blocks
TB 1 and TB 3, Figure 7.
Screens
Inputs are numbered 1 through 16, but only 8 inputs are shown at one time. The On/Off
status is shown under the input number; 0=Off, 1=On.
Selecting Inputs You may view inputs 1-8 or 9-16. Press SEL to toggle between the two groups of
inputs.
12345678 INPUT
01001001 1-8<
Input Numbers (1-8)
Input On/Off Status (0=Off, 1=On)
90123456 INPUT
01001001 9-16<
Input Numbers (9-16)
