6-19 Communications
Registers (Cont'd)
Speed Compensatin (Cont'd)
40274 Leading Edge Comp
Read/Write
Values: 0 - n (.1mS)
Specifies the leading edge speed comp value.
40275 Trailing Edge Comp
Read/Write
Values: 0 - n (.1mS)
Specifies the trailing edge speed comp value.
Timed Outputs
40276 Timed Output Mapping
Read/write
Values: 17 - 255
General purpose register used for mapping timed output values.
40277 Channel Index
Read/Write
Values: 1 - Max Channel Number
Channel index for time delay values.
40278 Time Delay
Read/write
Values: 0 - n (1mS)
Specifies the maximum time in milliseconds that a channel may stay on after it has bee
turned on.
Offset
40279 Offset Mapping
Read/write
Values: 17 - 256
General purpose register used for mapping Group Offset values.
40280 Group Index
Read/write
Values: 1 - 6
Group index for offset values.
40281 Group Offset
Read/write
Values: 0 - ( Scale Factor - 1 )
Offset value for the specified group.
Note that this value is a PRESET value for groups in modes 1 or 2.
Motion Detection
40282 Motion Detection Mapping
Read/write
Values: 17 - 255
General purpose register used for mapping low and high motion detection values. Two
registers will be used; the first will contain the low motion detection rpm value, the second will
contain the high motion detection rpm value.
40283 Channel Index
Read/write
Values: 1, 2
Motion detection level index for high and low motion detection values.
