3-13 Programming
Main Screen
Two Screens On power-up, or after five minutes of keypad inactivity, the controller will display one of
two main screens:
Main Screen— • One Output Group, and GRP POS DISP Set to “One” or “Each”
• Multiple Output Groups, and GRP POS DISP set to “One”
Main Screen— • Multiple Output Groups and GRP POS DISP set to “Each”
Active Program The PS-6144 can store up to 48 programs of setpoints. The “Active Program” is the
program currently controlling the output channels.
If hardware inputs are being used to select the Active Program, the display will
indicate the program selected by the inputs. If all hardware inputs are off, the Active
Program will be the Default Program specified through the DEFAULT PROGRAM func-
tion. For information on using hardware inputs to select the Active Program, see “Con-
troller Input Wiring” in Section 2.
If hardware inputs are not used, the Active Program will be the program specified
through the DEFAULT PROGRAM function.
Machine Speed When the machine is moving, Machine Speed is displayed in user selectable units of
RPM (revolutions per minute), BPM (bags per minute), or CPM (cartons per minute).
Machine Speed is displayed as a value which is 1X, 2X, or 3X the resolver RPM. See
RATE SETUP for details.
Toggle RPM Machine or Group Position is displayed only when the resolver speed is below the
TOGGLE RPM speed. At higher speeds, Machine Position will be blank. See TOGGLE
RPM for programming details.
Entering Menu Tree To enter the Menu Tree from the Main Screen, move the cursor to “MENU” and press
the SEL key.
See Also DEFAULT PROGRAM
RATE SETUP
TOGGLE RPM
GRP POS DISP
OFFSET
PGM: 1 RPM: 1500
MENU<
Machine position not shown above toggle RPM
PGM: 1 RPM: 1500
MENU< POS: 180 Machine Speed
Machine Position = Shaft Position + Offset
To enter Menu Tree, press SEL when cursor is here
Active Program
PGM: 1 RPM: 1500
MENU< GRP1: 180 Mode 1 or 2: Position = Preset + change since last reset
Mode 0, 3, 4, 5: Position = Shaft Position + Group Offset
Group #: To change, put cursor here and press SEL
To enter Menu Tree, put cursor here and press SEL
