Index 295
Index
common frequency reference 245
connectors
external triggering 114
external triggering source 115
front panel 9
rear panel 20
continuous
list sweep 49
step sweep 47
triggering 113
continuous wave
configuring 42
description 7
contrast adjustments 14
correction array (user flatness)
configuration 136
load from step array 137
viewing 137
See also user flatness correction
couplers/splitters, using 130
custom arb 80
custom arb waveform generator 8 , 159 – 179
custom mode 79
custom real-time I/Q baseband 8 , 181 – 200
CW mode
configuring 42
description 7
D
DAC over range error
128
DAC over-range errors 125 – 127
data
clock 191 , 192
encoding, differential 192 – 200
fields, editing 39
files 61
framed 112
input methods 65
patterns
triggering 111
using 182
removal 70
sensitive 65 , 70
storage
problems 287
security 65
See also instrument state register
See also memory catalog
unframed 112
DATA CLOCK connector 15 , 33
DATA connector 15 , 34
data filtering, pre or post fir 259 , 271
data sheets 1
data types 254
DC detector 46
DC offset 153
declassification 65
default FIR filter, restoring 164
default navigation data, GPS 212
delay, external trigger signal 113
Delete Item softkey 39
Delete Row softkey 39
description, adding & editing (instrument state) 64
detector
diode response 131
using 130
device clock source selection 262 , 268
DHCP 75
diagram
data types 254
diagrams
clock timing, parallel data 246
clock timing, parallel interleaved data 249
clock timing, phase and skew 251
clock timing, serial data 251
common frequency reference 245
differential data encoding 192 – 200
DIG BUS annunciator 17
Digital Bus connector 26
digital modulation
annunciators 19
custom 159 – 179 , 181 – 200
formats 8
multicarrier 159 , 161 , 178
multitone 221 – 229
two tone 231 – 236
digital signal interface 239
digital signal interface module 239
diode detector response 131
discrete steps, skew range 251
