Chapter 1 5
Signal Generator Overview
Signal Generator Models and Features
internal gated, and external pulse; internal triggered, internal doublet, and internal gated
require an external trigger source
— adjustable pulse rate
— adjustable pulse period
— adjustable pulse width (150 ns minimum)
— adjustable pulse delay
— selectable external pulse triggering: positive or negative
The E8663D PSG also offers the following optional features:
NOTE To provide analog frequency sweeps and for optimum swept scalar measurements with the
8757D scalar analyzer, the E8663D requires 007 (analog ramp sweep).
Option 007—analog ramp sweep
Option 008
1
—8 GB removable compact flash drive
Option 503—frequency range from 100 kHz to 3.2 GHz
Option 509—frequency range from 100 kHz to 9.0 GHz
Option 521—ultra 0.1- 3.2 GHz (with Option 503) or 0.1- 9 GHz (with Option 509) power
Option 1E1—step attenuator
Option 1EA (Discontinued)—high output power
Option 1ED—Type–N female RF output connector
Option 1EH —improved harmonics below 2 GHz
Option 1EU—high output power (standard with E8267D)
Option 1EM—moves all front panel connectors to the rear panel
Option 1EZ—extended support life
Option 1SM—provides improved performance in Exponential (Log) AM mode
Option UK6—commercial calibration certificate and test data
Option UNX—ultra low phase noise performance
Option UNY—enhanced ultra low phase noise performance
Option UNT—AM, FM, phase modulation, and LF output
• open–loop or closed–loop AM
• dc–synthesized FM to 10 MHz rates; maximum deviation depends on the carrier frequency
• external modulation inputs for AM, FM, and
M
1. Instruments with serial prefix

US4928/SG4928/MY4928.
