Chapter 12
247
Peripheral Devices
N5102A Digital Signal Interface Module
Figure 12-4
Clock Sample Timing for Parallel Port Configuration
1 Sample Period
Q sample
1 Clock Per Sample
1 Clock
Clock and sample rates are the same
I sample
Clock
4 bits per word
4 bits per word
