Page 89
Chapter 2
75
Basic Operation
Using the Web Server
c.
Verify that you want to reconfigure the signal generator with the new option:
Proceed With Reconfiguration
>
Confirm Change
The instrument enables the option and reboots.
Using the Web Server
You can communicate with the signal generator using the Web Server. This service uses TCP/IP
(Transmission Control Protocol/Internet Protocol) to communicate with the signal generator over the
internet.
The Web Server uses a client/server model where the client is the web browser on your PC or
workstation and the server is the signal generator. When you enable the Web Server, you can access
a web page that resides on the signal generator.
The Web–Enabled PSG web page, shown in
, provides general information on your signal
generator and a means to control the instrument by using a remote front panel interface or using
SCPI (Standard Communication for Programmable Instruments) commands. The web page also has
links to Agilent’s products, support, manuals, and website.
NOTE
The Web Server service is compatible with the latest version of the Microsoft© Internet
Explorer web browser.
1
The Signal Generator Web Control menu button on the Web–Enabled PSG web page will access a
second web page. This web page, shown in
, provides a virtual instrument interface that
can be used to control the signal generator. You can use the mouse to click on the signal generator’s
front panel hardkeys, softkeys and number pad. There is also a text box that can be used to send
SCPI commands to the instrument.
Activating the Web Server
Perform the following steps to access the Web Server.
1.
Turn on the Web Server by pressing
Utility
>
GPIB/RS–232 LAN
>
LAN Services Setup
>
Web Server On
.
2.
Press the
Proceed With Reconfiguration
softkey.
3.
Press the
Confirm Change
(Instrument will Reboot) softkey. The signal generator will reboot.
4.
Launch your PC or workstation web browser.
5.
Enter the IP address of the signal generator in the web browser address field. For example,
http://101.101.101.101. Replace 101.101.101.101 with your signal generator’s IP address. Press the
Enter
key on the computer’s keyboard.
NOTE
The IP (Internet Protocol) address can change depending on your LAN configuration.
Use the
LAN Config Manual DHCP
softkey to select a Manual or DHCP (dynamic host
communication protocol) LAN configuration. Refer to Agilent PSG Signal Generators Key
Reference for more information.
1.
Microsoft is a registered trademark of Microsoft Corp.
