MOD 30ML Multiloop Controller
MODULAR I/O CONNECTIONS
4.4.5 2011A Form C Mechanical Relay Outputs (WDOM)
Make mechanical relay output connections as shown in Figure 4-15.
Wire rating: 600 V, -20°C +105°C UL, CSA approved. Output specifications are:
FORM C MECHANICAL RELAY OUTPUT
Configuration Form C single relay
Power supply range + 5 VDC ±10%
Max Input Current -10.0 mA DC
Contact load 3A at 60 VAC or 30 VDC
Contact resistance 0.10 ohms maximum
Isolation 250 Vrms (contacts to coil)
Current rating 3A per relay
Response time 10 msec
72
