MOD 30ML Multiloop Controller
POWER, GROUNDING, AND BUILT-IN I/O CONNECTIONS
The input circuit and input signal specifications for each input type are shown in the following
sections:
 Volt, Millivolt and Thermocouple Input - Section 3.5.1
 RTD Input - Section 3.5.2
 Current Input from a 2-Wire Transmitter - Section 3.5.3
 Current Input from a Non 2-Wire Transmitter - Section 3.5.4
 Resistance Input - Section 3.5.5
General specifications for built-in process inputs are:
Input Isolation: Galvanic isolation using transformers and optical isolators.
Input Common Mode Rating: 45V dc
Common Mode Rejection: 120 dB @ 50/60 Hz
Normal Mode Noise Filter: 20 dB minimum @ 60 Hz
Maximum Normal Mode Voltage: 30V dc (except current input)
Display Accuracy: Input accuracy ± one least significant display digit
