MOD 30ML Multiloop Controller
APPENDIX A
CURRENT CONSUMPTION PLANNING FORM
CONTROLLER NUMBER ____
BUILT-IN I/O CURRENT CONSUMPTION
Description Max. Supply
Current (mA)
No. Used
(1 or 2)
Current
Subtotals
Transmitter Power Supply 150
20 mA Output 140
50 mA Output 410
ICN Terminator 100
Built-in I/O Current Subtotal /////////// ///////////
MODULAR I/O CURRENT CONSUMPTION
Catalog No. Description Max. Supply
Current (mA)
No. of
Modules
Current
Subtotals
2001A Model B Voltage Input 80
2002A Model B Current Input 80
2003A Model A Current Output 350
2004A Model A Solid State Relay Input 12
2005A Model A Solid State Relay Output 12
2006A Model A Nonisolated Digital Input 10
2007A Model A Nonisolated Digital Output 20
2009A Model B RTD Input 80
2011A Model A Mechanical Relay Output 140
2012A Model B Current Input with 2-Wire Transmitter 350
2013A Model B Thermocouple Input 80
2020N Model B Remote I/O Interface 400
2030N Model B ICN Communication With terminator
ICN Communication Without terminator
500
300
2032N Model C RS-485 2-Wire Communication 180
2033N Model A RS-232 Communication 180
2034N Model A RS-485 4-Wire Communication 180
Modular I/O Current Subtotal ////////// //////////
TOTAL CURRENT CONSUMPTION (must not exceed 5000 mA)
Base Instrument Load 1220 mA
Built-in I/O Current Subtotal mA
Modular I/O Current Subtotal mA
Total Current Consumption mA
A-2
