MOD 30ML Multiloop Controller
MODULAR I/O CONNECTIONS
4.3.2 2004A SSR Input (DIM)
Make Solid-State Relay (SSR) connections as shown in Figure 4-3. These input modules are
used for sensing ON/OFF voltage levels. Each module provides optical isolation between the
field devices and the control logic. This isolation is limited to 250 Vrms at the terminal block.
Typical uses and applications for these input modules include sensing voltage and contact
conditions from: proximity switches, limit switches, selector switches, push buttons,
photoelectric switches, TTL compatible devices, float switches, or thermostats.
Wire rating: 600 V, -20°C +105°C UL, CSA approved
 WARNING
All wiring connected to the controller terminals must be rated for the
maximum voltage present, or alternately, wiring in circuits operating at
greater than 30 volts must be rated for at least twice the circuit voltage.
Input specifications are:
DIGITAL INPUTS (ISOLATED)
_10_ _11_ _12_
Input voltage ranges 2.5-28Vdc 4-16Vdc 10-32Vdc, 12-32Vac
mA Input current at Max Line 30 45 25
Max Logic Low Input 1V, 0.2 mA 1V, 0.7 mA 3V, 1 mA
Input Resistance (Ohms) 900 300 1K (dc), 1.5K (ac)
Module Response Time (msec) 1.5 0.1 5
DIGITAL INPUTS (ISOLATED)
_13_ _14_ _15_
Input voltage ranges 35-60Vac/dc 90-140Vac/dc 180-280Vac/dc
mA Input current at Max Line 6 (dc), 25 (ac) 11 7
Max Logic Low Input 9V, 0.8 mA 45V, 3 mA 80V, 1.7 mA
Input Resistance 10K Ohms 14K Ohms 43K Ohms
Module Response Time (msec) 10 (dc), 15 (ac) 20 20
56
