4 2011a dual mechanical relay outputs (ddom) – Micromod MOD: 30ML Installation User Manual
Page 76
MOD 30ML Multiloop Controller
MODULAR I/O CONNECTIONS
4.4.4 2011A Dual Mechanical Relay Outputs (DDOM)
Make mechanical relay output connections as shown in Figure 4-14. Output specifications
are:
DUAL MECHANICAL RELAY OUTPUTS
Configuration
Dual relays (NO/NO, NC/NC, NO/NC)
Power supply range
+ 5 VDC ±10%
Max Input Current
-10.0 mA DC
Contact load
3A at 60 VAC or 30 VDC
Contact resistance
0.10 ohms maximum
Isolation
250 Vrms (contacts to coil)
Current rating
3A per relay
Response time
10 msec
70
