MOD 30ML Multiloop Controller
APPENDIX A
MOD 30ML I/O PLANNING FORM
Controller No.
Built-in I/O
Input 1:
Output 1:
Input 2:
Output 2:
Communications:
Modular I/O
I/O Module Locations
No. Module No. Module No. Module No. Module No. Module No. Module
S1 S2 S3 S4 S5 S6
S7 S8 S9 S10 S11 //////////
Figure A-1. Module Location Planning
A-3
