MOD 30ML Multiloop Controller

PRODUCT DESCRIPTION

1.3.6 2010P Portable Memory Module

The optional memory module plugs directly into the CPU board, Figure 1-1, and
provides a mechanism for porting a database from one instrument to another.
An instrument with this option can upload from or download to this module. The
memory module has a write protect setting to prevent accidental erasures.
When a memory module is installed in an instrument with the write protection
off, the operating software keeps the module up-to-date with all real time
changes in the instrument. Enhanced security is thereby provided through this
backup database copy. Data retention is typically 10 years with instrument
unpowered.

Catalog Number Description for 2010P
BASE NUMBER

2010P

Memory Module


UNUSED

Z

Unused Character


ELECTRICAL CODE

10

General Purpose


UNUSED

102

Unused Characters


MODEL

C

Design Level


Sample Number

2010PZ10102C (Product is serialized)

1.3.7 Downloading Cable

The MOD 30ML downloading cable is used with the built-in RS-232 port in the front of the
instrument. This cable cannot be used with the NEMA4 version of the controller as the front
port is not available in the NEMA4 version. The ViZapp Configuration Software includes one
cable.

Catalog Number for the Downloading cable

Sample Number

109S1854

11
