MOD 30ML Multiloop Controller
PRODUCT DESCRIPTION
1.4.6 2004A Solid-State Relay Input Module
The Solid-State Relay Input module provides the necessary interfacing for AC or DC digital
inputs when high isolation voltages are required (250V rms isolation limitation through
connection terminals). This module uses the Digital Input Module (DIM) Block for
configuration of input parameters.
DIM
Catalog Number Description for 2004A
BASE NUMBER 2004A Non-isolated Digital Input Module
UNUSED
P Unused Character
ELECTRICAL CODE
10 General Purpose
INPUT RANGE
10 2.5 to 28 VDC
11 4 to 16 VDC
12 10 to 32 VDC, 12 to 32 VAC
13 35 to 60 VAC / VDC
14 90 to 140 VAC / VDC
15 180 to 280 VAC / VDC
UNUSED
0 Unused Character
MODEL
A Design Level
Sample Number
2004AP10100A
1.4.7 2005A Solid-State Relay Output Module
The Solid-State Relay Output module provides the necessary interfacing for AC or DC digital
outputs when high isolation voltages are required (250V rms isolation limitation through
connection terminals). This module uses the Digital Output Module (DOM) Block for
configuration of output parameters.
DOM
Catalog Number Description for 2005A
BASE NUMBER 2005A Nonisolated Digital Input Module
UNUSED
P Unused Character
ELECTRICAL CODE 10
General Purpose
OUTPUT RANGE
10 5 to 60 VDC
11 5 to 200 VDC
12 12 to 140 VAC, SPST, NO
13 24 to 280 VAC, SPST, NO
14 24 to 280 VAC, SPST, NC
UNUSED
0 Unused Character
MODEL
A Design Level
Sample Number
2005AP10100A
15
