MOD 30ML Multiloop Controller
PRODUCT DESCRIPTION
1.4.8 2006A Nonisolated Digital Input Module
The Nonisolated Digital Input Module is primarily intended for instrument-to-instrument
signaling. The module interfaces 24-volt on/off signals with no isolation or accepts switch
contact closures without external power requirements. This module uses the Digital Input
Module (DIM) Block for configuration of input parameters.
DIM
Catalog Number Description for 2006A
BASE NUMBER 2006A Nonisolated Digital Input Module
UNUSED
Z Unused Character
ELECTRICAL CODE 10
General Purpose
INPUT RANGE
10 2.2 V to 24 VDC
UNUSED 0 Unused Character
MODEL
A Design Level
Sample Number
2006AZ10100A
1.4.9 2007A Nonisolated Digital Output Module
The Nonisolated Digital Output Module is primarily intended for instrument-to-instrument
signaling. The module interfaces 24-volt on/off signals with no isolation or works as an open
collector switch that also supports 5V TTL. This module uses the Digital Output Module
(DOM) Block for configuration of output parameters.
DOM
Catalog Number Description for 2007A
BASE NUMBER 2007A Nonisolated Digital Output Module
UNUSED
Z Unused Character
ELECTRICAL CODE 10
General Purpose
OUTPUT RANGE
10 24 V, 50 mA TTL
UNUSED
0 Unused Character
MODEL
A Design Level
Sample Number
2007AZ10100A
16
