Micromod MOD: 30ML Installation User Manual
Page 36
MOD 30ML Multiloop Controller
MECHANICAL INSTALLATION
30
Reattach the cover to the back of the hex
spacers with the #6 Phillips head
screws.
Note: When re-assembling the cable be
sure that the red striped edge of the
cable is at pin 1 end. This pin is either
marked with the number 1 or with a dot.
Panel
3
WARNING! Ensure red
stripe on cable lines up with
Pin 1 on connector
Panel
3
WARNING! Ensure red
stripe on cable lines up with
Pin 1 on connector
Panel
4
5
WARNING! Ensure red
stripe on cable lines up with
Pin 1 on connector
Panel
4
5
WARNING! Ensure red
stripe on cable lines up with
Pin 1 on connector
