MOD 30ML Multiloop Controller

MECHANICAL INSTALLATION

25

MOD 30ML I/O PLANNING FORM


Controller

No.


Built-in I/O

Input 1:

Thermocouple - Type J

Output 1:

20 mA

Input 2:

mA w/ 24 Vdc Transmitter Power Supply

Output 2:

20 mA

Communications:

4-Wire RS-485 Modbus (port 1)


Modular I/O

I/O Module Locations

No. Module No. Module No. Module No. Module No. Module No. Module

S1

S2 2005A

S3 2009A

S4 >--------- S5

S6 2003A

S7 2001A

S8

S9 2012A

S10

S11 2006A

////////////


Figure 2-1. Example of an I/O Planning Form for a Controller with I/O Modules
