MOD 30ML Multiloop Controller
PRODUCT DESCRIPTION
1.4.3 2012A Current Input Module (with 2-wire transmitter power)
This module is designed specifically for two-wire transmitters and provides the necessary 24
V DC current limited supply to power the transmitter. An internal current sense resistor
converts the current to a voltage for application to the A/D converter. All other features are
the same as the voltage input module. This module uses the Voltage/Current Input Module
(VCIM) Block for configuration of input parameters.
VCIM
Catalog Number Description for 2012A
BASE NUMBER
2012A
Current Input Module (with 2-wire transmitter power)
UNUSED
Z
Unused Character
ELECTRICAL CODE 10
General Purpose
INPUT RANGE
10
4 – 20 mA
ISOLATION
1
Isolated
MODEL
B
Design Level
Sample Number
2012AZ10101B
1.4.4 2013A Thermocouple Input Module (with upscale burnout detection)
The thermocouple input module is identical to the ±100 mV voltage input module except for
the addition of upscale burnout detection circuitry. Thermocouple types allowed are: B, E, J,
K, N, S, or T. This module uses the Thermocouple Input Module (TIM) Block for
configuration of input parameters.
Cold junction compensation (CJC) for all thermocouples is provided automatically by the
controller when this feature is enabled by connection of a thermocouple to built-in input 1. If
automatic CJC is not enabled, a 2009A RTD Input Module with a 2-wire CJC sensor must be
used to sense the temperature at the terminal block and provide CJC.
TIM
Catalog Number Description for 2013A
BASE NUMBER
2013A
Thermocouple Input Module
(with upscale burnout detection)
UNUSED
Z
Unused Character
ELECTRICAL CODE 10
General Purpose
INPUT RANGE
10
±100 mV
ISOLATION
1
Isolated
MODEL
B
Design Level
Sample Number
2013AZ10101B
