Megaject RTM Pro Manual – Revision 7.00 – 13
th
APRIL 2006
Module 3 - 1769-IQ32 : 32 point digital input module
Terminal Signal description
IN 0 Resin valve - recirculate
IN 1 Resin valve – inject
IN 2 Catalyst valve – inject
IN 3 Catalyst valve - recirculate
IN 4 Safety relay status (E-Stop)
IN 5 Catalyst over-pressure
IN 6 Start
IN 7 Stop
DC COM
IN 8 Air cylinder switch HI
IN 9 Air cylinder switch LO
IN 10 Solvent level
IN 11 Catalyst level
IN 12 Resin level
IN 13 Top motor home
IN 14 Bottom motor home
IN 15
DC COM
IN 16 Autosprue 1 open
IN 17 Autosprue 1 closed
IN 18 Autosprue 2 open
IN 19 Autosprue 2 closed
IN 20 Autosprue 3 open
IN 21 Autosprue 3 closed
IN 22 Autosprue 4 open
IN 23 Autosprue 4 closed
DC COM
IN 24 24VDC CONTROL POWER CHECK
IN 25
IN 26
IN 27
IN 28
IN 29
IN 30
IN 31
DC COM
