Megaject RTM Pro Manual – Revision 7.00 – 13
th
APRIL 2006
Figure 3.9 – Recipe edit screen 3 (Mould pressure control)
This feature can be used to more accurately control process times, when temperature
controlled tooling is not being utilised.
This mode can be enabled or disabled by toggling the button at the bottom of the
screen.
When enabled, a list of temperatures and adjustments is shown in the centre of the
screen. The temperatures range between 15
°
C and 30
°
C, and represent possible
ambient temperatures at the beginning of an automatic injection. For each temperature
a corresponding start and end catalyst compensation value is shown.
Figure 3.10 – Recipe edit screen 4 (Temperature compensation enabled)
If temperature compensation is enabled, when an injection begins, the machine reads
the ambient temperature in the workshop, and then uses the start and stop percentage
compensation values related to the closest temperature entry in the table. The
compensation values are added to the corresponding start and end percentages
specified in the recipe. If the result of this addition is below 0.5% or above 4.5% (out
of range) the closest in range percentage is used.
