- 49 - H.I.S. Instruction Manual
6. Apply o-ring on elbow and lubricate o-ring. Thread elbow into center section; align
elbow so tube hole in elbow is vertically up.
7. Slip o-rings on air tube. Install air tube in elbow after lubricating o-rings. Push air
tube in by hand until it bottoms out.
8. Place washer on piston. Align over piston rod hole.
9. Position cylinder head above cylinder on center section and screw piston keeper to
piston rod. Secure with suitable wrench. Align air tube with air tube hole in cylinder
head casting and push cylinder head down on cylinder.
10. Screw 3/8” diameter nuts onto cylinder tie rods. Drop bolts through holes common
to cylinder head and center section. Secure with nuts. Torque to 100 inch pounds
(8 1/3 foot pounds), sequencing opposite bolts.
11. Screw close nipple, oiler and pipe-to-hose fitting into cylinder head casting.
12. Screw orifice into flow control body and screw assembly into outlet hole in center
section. Use Teflon tape to insure a good seal.
Resin Pump Assembly Instructions
(P41 4:1 and P51 7:1)
The pump assembly procedure, as described, is the factory recommended procedure.
Magnum Venus Products will not be responsible for any damage incurred if
recommended procedure is not followed.
Components are first assembled to form subassemblies. The subassemblies, in turn,
when assembled form the completed pump. This procedure simplifies assembly process.
Upper Powerhead Unit
Refer to parts drawings for proper part numbers
(All powerhead parts should be lightly lubricated with LURBIPLATE®)
1. Screw valve actuator onto lower valve rod until holes align in valve actuator and
lower valve rod.
2. Tap roll pin through holes to secure valve actuator.
3. Slide piston keeper over lower valve rod (threads facing down).
4. Screw upper valve rod into lower valve rod using screwdriver slot in upper valve
rod. LOCTITE® thread sealer should be applied to help prevent rods separating.
5. Place proper o-ring into slot inside bushing.
6. Place proper o-ring into slot outside bushing.
7. Slide bushing (o-ring end down) over rod assembly.
8. Slide valve spring retainer (large diameter down) over upper valve rod. Retainer
will rest on lower valve rod.
9. Slide valve trip spring over upper valve rod and onto valve spring retainer.
10. Slide valve spool over upper valve rod and onto valve spring retainer.
11. Place two o-rings into grooves on valve spool.
12. Slide valve spool over upper valve rod (o-ring end first) and down on valve trip spring.
13. Slide second valve trip spring over upper valve rod and into valve spool. Slide
second valve spring retainer (small diameter first) over upper valve rod.
