Resin Pump Assembly
Introduction
The pump assembly procedure, as described, is the factory recommended procedure.
Magnum Venus Products will not be responsible for any damage incurred if
recommended procedure is not followed.
Components are first assembled to form subassemblies. The subassemblies, in turn,
when assembled form the completed pump. This procedure simplifies assembly process.
Resin Pump Assembly Instructions
(P21 11:1 and P31 10:1)
Magnum Venus Products recommends using the following materials where designated for
easy assembly, easy maintenance, maximum wear and for best operation of pumping
system:
A. Thread sealer such as LOCTITE®
B. Lubricate with 6706-2-1 special red grease (non-soluble in styrene) in all
areas of direct contact with resins.
C. Use 08465 LUBRIPLATE® (brown) grease to lubricate powerhead.
Upper Powerhead Unit
(Refer to parts drawings for proper part numbers)
1. Assembly valve springs washers (2) and valve spring on valve rod bolt as shown
on drawing (holding assembly in vise is recommended).
2. Apply LOCTITE® to thread on valve rod bolt and assemble to lower valve rod.
Wrench snug.
3. Slide piston keeper, thread down, on lower valve rod assembly.
4. Install proper o-ring in o-ring groove inside bushing.
5. Place o-ring in groove on bushing and lubricate both o-rings with LUBRIPLATE®.
6. Slide bushing on lower valve rod assembly, open end up.
7. Install lower valve keeper (not threaded) on top of lower valve rod (boss on
keeper facing up).
8. Screw lock nut onto lower end of upper valve rod (top end has screwdriver slot).
Apply LOCTITE® to lower threaded end and screw upper rod through lower valve
keeper and into lower valve rod (using screw driver slot). Tighten snugly. Bring lock
nut on upper valve rod down tight against lower valve keeper.
9. Place valve spool on upper valve rod (it will rest on lower valve keeper), ball
detents up. Thread upper valve keeper (boss down) onto upper valve rod
assembly. Secure, hand tight, against valve spool.
10. Screw ¼-28 lock nut on valve rod assembly. Hold valve keeper and wrench
tighten lock nut. Assembly is now locked end-to-end, and valve spool will not
