Operational ip phone features – Aastra Telecom SISIP 57I CT User Manual
Page 264
Operational Features
5-136
41-001160-00, Rev 01 Release 2.0
IP Phone Administrator Guide
Operational IP Phone Features
Aastra Web UI
For the 53i:
1
Click on Operation->Programmable Keys.
53i Screen
2
On the 53i, select a key from keys 1 through 6.
3
In the "Type" field, select XML from the list box.
4
On the 53i, in the "Label" field, enter a label that displays on the IP phone for the XML softkey. For
example, "aastra".
5
In the "Value" field, enter the URI that the phone performs a GET on when the key is pressed. For
example:
http://10.50.10.140/script.pl?name=$$SIPUSERNAME$$
Note: You can use the following variables in the URI:
•
$$SIPUSERNAME$$
•
$$SIPAUTHNAME$$
•
$$PROXYURL$$
•
$$REMOTENUMBER$$
•
$$DISPLAYNAME$$
•
$$INCOMINGNAME$$
6
Click
to save your changes.
You must restart your IP phone for the changes to take affect.
