Operational Features
41-001160-00, Rev 01 Release 2.0 5-135
Operational IP Phone Features
Operational IP Phone Features
3 In the "Type" field, select XML from the list box.
4 In the "Label" field, enter a label that displays on the IP phone for the XML softkey. For example,
"aastra".
5 In the "Value" field, enter the URI that the phone performs a GET on when the key is pressed. For
example:
http://10.50.10.140/script.pl?name=$$SIPUSERNAME$$
Note: You can use the following variables in the URI:
•
$$SIPUSERNAME$$
• $$SIPAUTHNAME$$
• $$PROXYURL$$
• $$REMOTENUMBER$$
• $$DISPLAYNAME$$
• $$INCOMINGNAME$$
6 Click to save your changes.
You must restart your IP phone for the changes to take affect.
Aastra Web UI
