62
Standard Operations
3. The Profibus/Modbus configuration screen is displayed.
4. Press the ADD button and select a device. The Select device box is displayed
( Figure 45 ).
Figure 44 Profibus/Modbus configuration menu
1 ENTER button—Saves configuration and returns to the
FIELDBUS menu
4 DELETE button—Removes a device/tag from the
Telegram
2 CANCEL button—Returns to the FIELDBUS menu without
saving
5 UP/DOWN arrow—Moves device/tag up and down
3 ADD button—Adds new device/tag to the Telegram
Figure 45 Profibus/Modbus configuration menu — Select device
