125
Troubleshooting
8.5 Test the expansion cards in the Maintenance menu
8.5.1 Test the output card
In the TEST/MAINT menu, every output current can be set to certain values for testing
reasons. If necessary, each output can be adjusted as well. Additionally, the current state
of the outputs can be requested.
The output current can be set to certain values and then be adjusted with an offset and a
factor.
To set these two parameters:
1. Set the SET OFFSET value to “0” and the SET FACTOR value to “1”.
2. Set the output current (CURRENT OUT) to “4 mA” and then only adjust the SET
OFFSET value until the output current is really 4 mA.
3. Set the output current (CURRENT OUT) value to “20 mA”, then adjust the factor until
the output current is really 20 mA and cross-check the 4 mA.
4. Repeat the steps 1-3 until the output precision reaches a desired value.
Table 48 SMS format description
Information Description
Message type
W=Warning, E=Error, P=Process Events
For example: =Communication error
FACILITY
Addresser information
Refer to MENU, sc1000 SETUP, DISPLAY SETTINGS, FACILITY
LOCATION
Addresser information.
Refer to sc1000 SETUP, DISPLAY SETTINGS, LOCATION
SIM Card Data
Telephone number for remote access connections.
Refer to sc1000 SETUP, GSM MODULE, SIM CARD DATA
Serial number
sc1000
Serial number of sc1000 controller.
Probe name Name of probe who has caused this message.
Probe location Location of probe who has caused this message.
Serial number
probe
Serial number of probe who has caused this message.
Text Error, warning or event text.
Date Date (Format: YYMMDD) of last occurrence.
Time Time (Format: HHMM) of last occurrence.
Manufacturer ID Manufacturer ID
Instrument ID Instrument ID
Table 49 SMS example
E32 HACH-LANGE Trailer 01726428973 000001138172 RELAY INT Reservoir 1
000000002283 COMMUNICATION ER 061128 1332 001 49155
