116
Advanced Operations
6.3.12 SYSTEM SETUP/LICENSE MANAGEMENT
Used to activate or remove software features from the system. The features that are
activated for this controler will also be displayed in this menu.
• NEW LICENSE: Enter license code to activate new feature.
• UNINSTALL SOFTWARE: Remove an installed software package.
6.3.13 SYSTEM SETUP/MODBUS TCP
Refer to Section 4.4.1 at the Manual DOC023.XX.90143 „sc1000 enhanced
communications".
6.4 Test/Maint Menu
The Test/Maint menu enables a user to test internal plug-in expansion cards and external
DIN rail modules.
For more detailed information refer to Section 8 .
TEST/MAINT
DATALOG SETUP
ERASE DATA/
EVENT LOG
Select the device to delete from the data or event log.
TEST/MAINT
OUTPUT SETUP
mA Output INT/EXT
FUNCTION TEST Test the outputs on the selected card/module.
STATUS OUTPUT Displays the status of the outputs on the selected card/module.
TEST/MAINT
CURRENT INPUT
mA Input INT/EXT
FUNCTION TEST Test the inputs on the selected card/module.
TEST/MAINT
RELAY
Relay INT/EXT
FUNCTION TEST Tests the relays on the selected card/module.
RELAY STATUS Displays the status of the outputs for the relay cards.
TEST/MAINT
NETWORK MODULES
FIELDBUS
SOFTWARE
VERSION
Displays the network modules software version
