130
Replacement Parts and Accessories
External SD 1 GB kit
1
YAB096
External antenna
1
LZX990
Extension cable for external antenna
1
LZX955
9.5 Replacement parts
Refer to Exploded view drawings,
Figure 70 on page 132
Item
Description
Item No.
1
Probe module, Front housing (HACH)
LZX949
1
Probe module, Front housing (LANGE)
LZX950
2
Brand label (HACH)
LZX951
2
Brand label (LANGE)
LZX952
3
Set of screws probe module
LZX973
4
Cover for power supply
LZX983
5
Probe module gasket
LZX954
6
Back housing
LZX953
7
sc analyzer power connectors (2 pieces)
LZX970
8
Conduit connector
LZX981
9
Strain relief for power cord M20
LZX980
10
Protection cap
LZX982
11
sc sensor connectors (2 pieces)
LZX969
12
Strain relief (2 pieces) M16 × 1.5
LZX978
13
Strain relief for relays M20
LZX932
14
Set of screws (internal)
LZX974
15
Set of screws (external)
LZX975
16
Set of caps
LZX979
20
sc1000-bus plug (sc1000 internal network connector)
LZX918
21
Cap D_Sub 9 (sc1000 internal network connector cover)
LZX977
22
Input plug-in board analog/digital
YAB018
23
Output plug-in board
YAB019
24
Profibus DP plug-in board (up to 2013)
YAB020
24
Profibus DP plug-in board (since 2013)
YAB105
25
MODBUS RS485 plug-in board
YAB021
25
MODBUS RS232 plug-in board
YAB047
26
Set of screws (internal) for BUS boards
LZX910
27
Cover for relays
LZX968
29
Relay plug-in board
YAB076
30
Air fan
LZX962
31
LED board sc1000
YAB025
32
Power supply 100-240 VAC
YAB039
33
Power supply 24 VDC
YAB027
34
Fuses set
LZX976
35
Termination board
YAB024
9.4 Accessories
Description
QTY
Item No.
