Installation

Figure 31 Network connector components

1

Housing, network connector

7

Insert, plastic label (network connector housing)

2

Network connector printed circuit board with shell bottom

8

Not used

3

Shell, top

9

Plug, rubber, cord grip

4

Screws, self-tapping (2×)

10 Seal, cord grip (2×)

5

Clamp, network cable(s)

11 Cord grip (2×)

6

Screw, pan head
