111
Advanced Operations
sc1000 SETUP
GSM MODULE
PROVIDER
Displays the current mobile network.
SIGNAL STRENGTH
Displays the radio signal strength (0 %
–
100 %)
STATUS
Displays the current status of the GSM modem:
INITIALIZATION
The display module initializes the GSM modem
NO SIM CARD
Refer to
on how to insert a SIM card.
WRONG PIN
The configured PIN number is not correct.
SEARCHING
NETWORK
The GSM modem tries to connect to the SIM card (mobile network).
INCOMMING CALL
The GSM modem detects an incoming call.
CONNECTION
The GSM modem accepts the call and is online.
READY
The GSM modem is ready for operation.
LINK CONNECTION
The GSM modem tries to establish a GPRS connection.
GPRS CONNECTION
The GSM modem has established a GPRS connection.
GPRS
GPRS
ON/OFF Switch GPRS Mode on/off.
STATUS
Display the status of the GSM modem.
IP ADDRESS
Assigned IP address provided by the mobile network operator.
DIAL-IN NUMBER
For internal use only.
APN
Access Point Name provided by mobile network operator.
USERNAME
Username provided by mobile network operator.
PASSWORD
Password provided by mobile network operator.
PING
Can be used for periodicaly connectivity test.
ADSRESS
URL or IP address for destination to be pinged.
set interval
Time interval for ping.
EXTERNAL DIAL-UP
ALLOWED
Remote access via GSM modem is allowed.
DENIED
The GSM modem doesn't answer incoming calls. SMS shipping is always possible!
IP SERVER
Displays the IP address of the display module. To access the display module via your web
browser, enter this IP address into the web browser address field. The default IP address
192.168.154.30 is always valid for remote access.
IP CLIENT
Displays the IP address of the remote computer.
SMS DESTINATION
NUMBER SERVICE
Contains the same functionality like SMS DESTINATION 1-4, but it is password protected with
the MAINTANENCE password.
SMS DESTINATION 1-4
SMS DESTINATION
SMS receptors telephone number.
LANGUAGE
Selects a language for SMS text.
Note: The character set for SMS text is limited to the GSM alphabet. Some languages contain
not supported characters. Not supported characters are replaced with a '?'.
SMS LIMIT
(0
–
100)
Sets the maximum number of SMS messages the display module is allowed to send out within
24 hours for this SMS DESTINATION. The 24h cycle starts at the at the set START TIME.
REPEAT
(0
–
24 hours)
Sets an interval for the repeat cycle.
The interval determines the frequency of sending not confirmed messages to the SMS
destination.
