58
Standard Operations
5.4 The Main menu display
If the MAIN MENU button (from the pop-up toolbar) is selected, the main menu display is
opened. The main menu display allows the user to view the sensor status, configure the
sensor setup, sc1000 setup and perform diagnostics. The menu structure of the main
menu may vary, depending on the configuration of the system.
5.5 The alphanumeric keypad
The keypad pops up automatically if it is necessary to enter characters or numbers to a
configuration setting.
This display is used to enter letters, numbers and symbols as needed when programming
the instrument. Unavailable options are disabled (grayed out). The icons on the right and
left of the screen are described in
Figure 43 .
The central keypad changes to reflect the chosen entry mode. Press a key repeatedly until
the desired character appears on the screen. A space can be entered by using the
underscore on the
0_? key.
Figure 42 Main menu (Menu item language depends on the selected display language)
1 LEFT/RIGHT arrow button—Moves back and forth in the
menu structure.
4 HOME button—Moves to the main measurement screen
from any other screen. This button is not active in
menus where a selection or other input must be made.
2 ENTER button—Accepts an input value, updates, or
accepts displayed menu options.
5 UP/DOWN arrow—Scrolls the menu items.
3 FAVORITES button—Displays/Adds favorites.
