14
Operating
7.2.2. function of the Dip switches
on
1 2 3 4
DiP-
Switches
Position Function
1 ON Reversal of the effective direction of the
set-point value (
DIR.CMD)
(set-point value 20 – 4 mA corresponds to
position 0 – 100%)
OFF Normal effective direction of the set-point
value (set-point value 4 – 20 mA corre-
sponds to position 0 – 100%)
2 ON Sealing function active.
The valve completely closes below 2%
5)
and opens above 98% of the set-point
value (
CUTOFF)
OFF No sealing function
DiP-
Switches
Position Function
3 ON Correction characteristic for adjustment of
the operating characteristic (Linearization of
the operating characteristic
CHARACT) 6)
OFF Linear characteristic
4 ON MANUAL operating status
OFF AUTO AUTOMATIC operating status
5)
Factory setting can be changed via communications software.
6)
Characteristic type can be changed via communications
software.
Tab. 3: Function of the DIP switches
information about the communications software:
The switching position of the DIP switch has priority over
the communications software!
If the values of the sealing function (
CUTOFF) or the cor-
rection characteristic ( CHARACT) are changed via the
software tool, the corresponding function must be active
(DIP switch set to ON).
The effective direction of the set-point value (
DIR.CMD) can
be changed via the DIP switches.
english
Type 8791
