40
Spareparts
Type 2035 / 3236
14. spare parTs
Warning
risk of injury when opening the actuator.
The actuator contains a tensioned spring. If the actuator is opened,
there is a risk of injury because the spring may jump out.
▶ The actuator must not be opened.
Caution!
risk of injury and/or damage by the use of incorrect parts.
Incorrect accessories and unsuitable spare parts may cause injuries
and damage the device and the surrounding area.
▶ Use original accessories and original spare parts from Bürkert only.
The diaphragm is available as a spare part for the diaphragm valve
Type 2035 / 3236.
If you have any queries, please contact your Bürkert sales
office.
14.1. Order table
size Order numbers for diaphragms
epdm
code aB
pfa/epdm
code pn epdm
customized
code ac
RV50 207334 207338 207352
RV70 207339 207341 207350
RV110 207344 207345 207349
Tab. 4: Diaphragm ordering table
Other diaphragms on request.
english
