Output selection settings

Working with Native Matrix Mode

To set up the outputs, go in the

Output

menu and choose first the appropirate for-

mat/resolution and then the adapted rate for your screens by using the knob button and the Enter

button.

Output# → Output Format → Output rate

You can also in the

Output 2

menu, synchronise all the changes from the

Output

to the

Output

by checking the case

Synch w/Out 1

. It allows you to set up both outputs at the same time.

Output

2 → Synch w/Out 1

* NOTE *: The output status can provide you all information about the output in real time. This fea-

ture is particularly needed when HDCP is used thanks to the HDCP status.

*All changes have to be validated by pressing the OK button in order to be saved*

Video Out

Almost the same than in mixer mode except that in Native Matrix mode, the menu “connection

mode” appears. It allows you to choose recording Output #1 or Output #2.

To activate the Native Matrix Mode:

Mode Menu → Native Matrix mode menu → Standard Mode or Mirror Mode

Display Mode

Presentation

Availability

YES

OUT #1

OUT #2

Output #1

Output #2

Menu→ Video Out → Connection →

Output #1

Menu→ Video Out → Connection →

Output #2
