To configure audio settings of the

Eikos LE, plug all audio inputs into the device, and navigate to

the Audio Menu.

1. Choose the audio mode, Break Away or Top Layer Follow, which you wish the audio to work in.

* NOTE * : the Break Away mode will route the selected audio source, while the Top Layer Follow

mode will route audio from the topmost active layer of the

Eikos LE.

2. Select Source Settings from the Audio menu to select the audio source you wish to work with,

then set levels and left/right balance for each input.

3. Select Auxiliary Settings to determine level and balance of the auxiliary input.

* NOTE * : the auxiliary input is combined with the selected input.

4. In Mixer Mode, select the Main Output menu to determine main audio output level, balance and

delay settings, or to mute main audio output.

* NOTE * : in Matrix Mode, all output parameters can be assigned separately to outputs

1 and

5. In Mixer Mode, select Audio Prelist, from the Audio menu, to determine pre-listen audio output

level, balance and delay settings, for each audio input, or to mute Prelist audio output.

* NOTE * : in Matrix Mode, select Out1 Prelist or Out2 Prelist from the Audio menu to set audio

pre-listen output parameters.

6. Select Delay Mode, to determine how the

Eikos LE deals with audio delay. Select Auto Adjust to let

the

Eikos LE determine audio output delay. Select Manual Adjust to determine audio delay manually.

* NOTE * : selecting Manual Adjust will give access to audio delay value (in milliseconds) of the

main and Prelist audio output menus.

Audio configuration

Working with Audio

The

Eikos LE allows to work with up to 10 stereo inputs, 1 auxiliary input, and 2 stereo embedded

SDI audio inputs (via the SDI BNC connectors), all accessible via the Audio menu of the

Eikos LE,

and which can be assigned to one or both of the 2 independant symetrical/asymetrical outputs of the

device.

Creating Presets

The

Eikos LE allows the creation of user defined presets very easily. Any setup you have configured

on screen, can be stored into one of the 4 available user presets.
1. After having configured layers, PIP transitions, logos... on your screen (see Working with the

Eikos LE, p.32), go to the Preset menu by pressing the EXIT/MENU button, and select Preset by

rotating the scroll knob. Then, press the ENTER button to enter the Preset sub-menu. Choose

Preset Copy by scrolling with the corresponding knob, and press the ENTER button to access

the sub-menu.

2. In the sub-menu, choose Save From Main or Save From Preview to determine which screen you

want to memorize the preset from, then set the preset memory (#1-#8) you wish to use as your

“User Preset” (by default, the

Eikos LE will choose the next available preset in the Eikos LE

memory).

3. By pressing the ENTER button, the

Eikos LE will ask you to confirm. Select Yes, your screen is

memorized as a preset.
