Analog Way Octo Value - Manual

• We recommend resetting the device to all of its default
values, with the front panel LCD menu (CONTROL >
default value > yes) before proceeding.
• Select the fast or seamless switching mode with
the LCD menu ( SWITCHING > fast switching or
seamless).
• Select the Auto settings function with the LCD menu
( INPUT > Auto settings). This function will detect
automatically the source type connected to the inputs
of the device. Sometimes, the auto setting may not
detect the source type : in this case select manually
the source type with the LCD menu ( INPUT > Input
type).
• If you have selected the fast switching mode: select
one of the output formats with the LCD menu
( OUTPUT > output format). Then select the output
rate with the LCD menu ( OUTPUT > output rate).
• Display device adjustment :
- IN SEAMLESS MODE: Select the reference
computer source. The reference computer image
is displayed onto the output. Adjust directly the
display device itself, using its position and size
controls, to fill the computer image in full screen.
- IN FAST SWITCHING MODE: Display
the centering pattern with the LCD menu
( OUTPUT > test pattern > centering). Display
a black output. Adjust directly the display device
itself, using its position and size controls, to fill the
centering pattern in full screen.
• For each input source connected to the device, make
the following adjustments:
- Select the source you want to adjust (with the
front panel “ INPUT SELECTION” buttons).
- Select the aspect ratio of your input source with
the LCD menu ( IMAGE > aspect ratio).
- Use the Centering function ( IMAGE >
centering) to automatically position the image in
the Centering pattern.
- As required, make the other adjustments,
available in the LCD IMAGE menu (color,
brightness…).
QUICK START GUIDE
What’s in the box
Octo Value settings
Thank you for choosing Analog Way and the Octo Value . By following these simple steps, you will be able to setup and
use your powerfull scaler/switcher within minutes. Discover the Octo Value extensive capabilities and intuitive interface
while configuring your first show, and unleash your creativity for a new experience in show and event management by
Analog Way .
Octo Value - Ref. OXE831
1 x Octo Value (OXE831)
1 x AC Power supply cord
1 x HD15 male / 5 x BNC female cable adaptor
1 x HD15 female / DVI-I male adaptor
1 x Set of 5 MCO (5-pin) female connectors
1 x RCS - Remote Control Software *
1 x User Manual (PDF version) *
* Download on our website: www.analogway.com
