Introduction
OSCAR Technical Manual V2.4.0
9
Introduction
This OSCAR Technical Manual describes in depth the technical specifica-
tions, dimensions, all camera features (IIDC standard and AVT smart fea-
tures) and their registers, trigger features, all video and color formats, band-
width and frame rate calculation.
For information on hardware installation, safety warnings, pin assignments
on I/O connectors and 1394a connectors read the Hardware Installation
Guide.
Document history
Note
L
Please read through this manual carefully.
We assume that you have read already the Hardware
Installation Guide and that you have installed the hard-
ware and software on your PC or laptop (FireWire card,
cables).
Version Date Remarks
1.0 10.05.2005 First issue
1.1 25.08.2005 Oscar F-510C: firmware 1.05/3.00; minor corrections and clari-
fications
2.0.0 14.03.2006 Manual compliant to firmware 3.03, added feature user profiles,
minor corrections
2.0.1 15.03.2006 All Oscar cameras are Class B compliant.
2.1.0 28.06.2006 New layout, manual compliant to firmware 3.04, RoHS confor-
mity, minor corrections
2.1.1 18.09.2006 Corrected BAYER demosaicing interpolation formula (Chapter
Color interpolation (BAYER demosaicing) on page 91)
Minor corrections
2.2.0 26.10.2006 Added Format_7 binning modes for Oscar F-510C (Chapter
Oscar F-510C on page 23, Chapter Binning (only Oscar F-510C)
on page 84 and Chapter Video formats: Oscar F-510C on page
123)
Minor corrections
to be continued on next page
Table 1: Document history
