Configuration of the camera
OSCAR Technical Manual V2.4.0
177
Version information register
The presence of each of the following features can be queried by the 0 bit of
the corresponding register.
This register holds information about the node_hw_version, the
node_sw_version and the node_spec_ID (camera type). µC version and FPGA
version are bcd-coded, which means that e.g. firmware version 0.85 is read
as 0x0085.
The FPGA type ID (= camera type ID) identifies the camera type with the help
of the following list:
Note
L
Always activate advanced features before accessing them.
Note
L
• Currently all registers can be written without being
activated. This makes it easier to operate the camera
using Directcontrol.
• AVT reserves the right to require activation in future
versions of the software.
Register Name Field Bit Description
0xF1000010 VERSION_INFO1 µC type ID [0..15] Reserved
µC version [16..31] Bcd-coded version number
0xF1000014 [0..31] Reserved
0xF1000018 VERSION_INFO3 Camera type ID [0..15] See below
FPGA version [16..31] Bcd-coded version number
0xF100001C [0..31] Reserved
Table 81: Advanced register: Version information
ID (decimal) Camera type
1 F145b
2 F145c
3 F201b
4 F201c
5 F145b-1
Table 82: Camera type ID list
